DESCRIPTION
Building on our award-winning 52|63 wheel platform, 57|64 wheels are over 8% faster in wind tunnel testing, without adding a single gram of weight to the rim.
Designed with our latest Turbulent Aero refinements, it’s the ultimate wheelset for breakaways, sprints, and all-out speed. The 57mm tall front rim ensures confident handling in crosswinds, while the 64mm tall rear rim delivers relentless aero gains. Updated with our sleek new graphics, it’s fast; redefined.
SPECIFICATIONS
-
Designed For
Road racing, crits, and fast group rides -
Wheelset Weight
DT 180 Dicut - 1554g , DT 240 - 1574 , DT 350 - 1634g -
ERD
527mm (57), 515mm (64) -
Inner Width
25.4mm Front, 24.4mm Rear -
External Width
34.3mm Front, 32.5mm Rear -
Depth
57mm Front, 64mm Rear -
Offset Rear
1.3mm -
Recommended Tire Dimensions
29 to 40mm -
Rim Weights
465g (57), 525g (64) -
Spoke Count
24 -
Hub Spacing
12X100mm/12X142mm -
Freehub Options
XDR, HG-EV -
Disc Style Option
Centerlock -
Tire Compatibility
Tubeless, Clincher -
Rim Bead
Semi-hooked
WHAT'S IN THE BOX
- 1x Complete wheelset
- XDr + HG-EV driver (DT 180 only)
- 29mm Reserve Rim Tape (installed)
- 2x 90mm Fillmore Tubeless Valves (un-installed)
- White Reserve Rim Decals (un-installed)
- User Manual
